2 DB Connection Settings
2-11
NJ/NX-series Database Connection CPU Units User’s Manual (W527)
2
2-2 DB Connection Settings
2-2-2 DB Connection Settings
Category Item Description Value
User name Set the user name for the server.  DB2: Windows user name of the server
 Other DBs: DB user name of the server
Maximum number of characters:
127 characters
Default: Blank
Password Set the password for the server.  DB2: Windows password of the server
 Other DBs: DB password of the server
Maximum number of characters:
127 characters
Default: Blank
Login timeout Set the timeout to be applied when
connecting to the DB.
1 to 60 seconds
Default: 10 seconds
Query execution
timeout
Set the timeout to be applied at the
SQL execution.
1 to 600 seconds
Default: 30 seconds
Comment Enter a comment. Maximum number of bytes: 1,024 bytes
Default: Blank
The comment can be omitted.
* When you specify a server by its host name, you need to set DNS to Use or make the host settings in the Built-in
EtherNet/IP Port Settings. Refer to the NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (Cat. No.
W506) for details on the settings.
Version Information
When you use an NX701-@@20, NJ501-1@20, or NJ101-@@20, the supported database
types depend on the combination of the DB Connection Service version of the CPU Unit
and the DB Connection Service version set in the Sysmac Studio project.
For the relationship between the unit version of the CPU Unit and the unit version set in
the Sysmac Studio project, refer to Section B-4-3 Actual Unit Version of CPU Unit and Unit
Version Set in the Sysmac Studio Project.
