2-8
2-1 Standard Models
2
Standard Models and Dimensions
Note1. The standard models have a straight shaft.
Note2. Models with a key and tap are indicated with "J" at the end of the model number (the suffix
shown in the box). (Example: R88G-HPG11A05100BJ)
Specifications
Model
Motor
capacity
Gear ratio
1 kW
1/5 R88G-HPG32A051K0B
@
1/11 R88G-HPG32A111K0B@
1/21 R88G-HPG32A211K0B@
1/33 R88G-HPG32A331K0B@
1/45 R88G-HPG50A451K0B@
1.5 kW
1/5 R88G-HPG32A052K0B
@
1/11 R88G-HPG32A112K0B@
1/21 R88G-HPG32A211K5B@
1/33 R88G-HPG50A332K0B@
1/45 R88G-HPG50A451K5B@
2 kW
1/5 R88G-HPG32A052K0B
@
1/11 R88G-HPG32A112K0B@
1/21 R88G-HPG50A212K0B@
1/33 R88G-HPG50A332K0B@
3 kW
1/5 R88G-HPG32A053K0B
@
1/11 R88G-HPG50A113K0B@
1/21 R88G-HPG50A213K0B@
4 kW
1/5 R88G-HPG32A054K0B
@
1/11 R88G-HPG50A115K0B@
5 kW
1/5 R88G-HPG50A055K0B
@
1/11 R88G-HPG50A115K0B@
