2-7

2-1 Standard Models

Standard Models and Dimensions

Decelerators

The following types of Decelerators are available for OMNUC G-Series Servomotors. Select a

Decelerator based on the Servomotor capacity.

 Backlash = 3’ Max.

Decelerators for 3,000-r/min Servomotors

Specifications

Model

Motor

capacity

Gear ratio

50 W

1/5 R88G-HPG11A05100B

1/9 R88G-HPG11A09050B@

1/21 R88G-HPG14A21100B@

1/33 R88G-HPG14A33050B@

1/45 R88G-HPG14A45050B@

100 W

1/5 R88G-HPG11A05100B

1/11 R88G-HPG14A11100B@

1/21 R88G-HPG14A21100B@

1/33 R88G-HPG20A33100B@

1/45 R88G-HPG20A45100B@

200 W

1/5 R88G-HPG14A05200B

1/11 R88G-HPG14A11200B@

1/21 R88G-HPG20A21200B@

1/33 R88G-HPG20A33200B@

1/45 R88G-HPG20A45200B@

400 W

1/5 R88G-HPG14A05400B

1/11 R88G-HPG20A11400B@

1/21 R88G-HPG20A21400B@

1/33 R88G-HPG32A33400B@

1/45 R88G-HPG32A45400B@

750 W

1/5 R88G-HPG20A05750B

1/11 R88G-HPG20A11750B@

1/21 R88G-HPG32A21750B@

1/33 R88G-HPG32A33750B@

1/45 R88G-HPG32A45750B@
