10
Installation and Wiring Precautions
Caution Do not step on or place a heavy object on the product. Doing so may result in injury.
Caution Do not cover the inlet or outlet ports and prevent any foreign objects from entering
the product. Doing so may result in fire.
Caution Be sure to install the product in the correct direction. Not doing so may result in mal-
function.
Caution Provide the specified clearances between the Servo Driver and the control panel or
with other devices. Not doing so may result in fire or malfunction.
Caution Do not apply any strong impact. Doing so may result in malfunction.
Caution Be sure to wire correctly and securely. Not doing so may result in motor runaway,
injury, or malfunction.
Caution Be sure that all the mounting screws, terminal screws, and cable connector screws
are tightened to the torque specified in the relevant manuals. Incorrect tightening
torque may result in malfunction.
Caution Use crimp terminals for wiring. Do not connect bare stranded wires directly to termi-
nals. Connection of bare stranded wires may result in burning.
Caution Always use the power supply voltage specified in the User’s Manual. An incorrect
voltage may result in malfunction or burning.
Caution Take appropriate measures to ensure that the specified power with the rated voltage
and frequency is supplied. Be particularly careful in places where the power supply
is unstable. An incorrect power supply may result in malfunction.
Caution Install external breakers and take other safety measures against short-circuiting in
external wiring. Insufficient safety measures against short-circuiting may result in
burning.
Caution Provide an appropriate stopping device on the machine side to secure safety. (A
holding brake is not a stopping device for securing safety.) Not doing so may result in
injury.
Caution Provide an external emergency stopping device that allows an instantaneous stop of
operation and power interruption. Not doing so may result in injury.
Caution Take appropriate and sufficient countermeasures when installing systems in the fol-
lowing locations:
S Locations subject to static electricity or other forms of noise.
S Locations subject to strong electromagnetic fields and magnetic fields.
S Locations subject to possible exposure to radioactivity.
S Locations close to power supplies.
System Design and Installation
Chapter 2
