Omron OMNUC U R88M-U Series User Manual

11
2-1 Installation
2-1-1 External Dimensions (Unit: mm)
H AC Servo Drivers Conforming to UL/cUL Standards and AC
Servomotors Not Conforming to Any Standards
D R88D-UP02H(A)/UP03H(A)/UP04H(A)/UP08H(A) (200 VAC, 30 to 200 W)
R88D-UP03L(A)/UP04L(A)/UP10L(A) (100 VAC, 30 to 100 W)
160
149
R3
Three, M4
55 130
5
4
5
45 (5) 45
6
5
(165)
149
(6)
Installation dimensions
Two,
6 dia.
D R88D-UP12H(A) (200 VAC, 400 W) and R88D-UP12L(A) (100 VAC, 200 W)
5
4
75 130 60 (5)
5
(6)
160
(165)
5
6
149
149
60
R3
Three, M4
Two,
6 dia.
Installation dimensions
System Design and Installation
Chapter 2
