Installation and Wiring Precautions
Caution Do
not stand on the product or put heavy objects on the product. Doing
so may result
in an injury.
Caution Make
sure that the product is
well ventilated and the interior of the product is free of
foreign matter. Not doing so may result in a fire.
Caution Mount the product properly. Not doing so may result in a product malfunction.
Caution Keep
the specified distance between
the Servo Driver and the interior surface of the
control
panel or any other machine. Not doing so may result in a fire or Servomotor
malfunction.
Caution Protect
the product from excessive shock. Not doing so may
result in a product mal
-
function.
Caution Wire
the system correctly
. Not doing so may result in an out-of-control Servomotor
and injury.
Caution Tighten mounting screws, terminal screws, and cable connector screws firmly.
Loose screws may result in a product malfunction.
Caution Use
crimp terminals when wiring. Connecting bare twisted wires
directly to terminals
may result in fires.
Caution Use the power supply voltages specified in this manual. Incorrect voltages may
damage the product.
Caution Take
steps to ensure that the rated power supply voltage is maintained in
locations
with poor power supply conditions. Improper power supply voltages may damage
the product.
Caution Install
safety measures, such as circuit breakers, to protect against
shorts in external
wiring. Insufficient safety measures may result in fires.
Caution Install
a safety stop on each machine. Not doing so may result in an injury
. A brake is
not considered a safety stop.
Caution Install
an emergency stop to shut of
f power to the system instantly
. Not doing so may
result in an injury.
Caution Take
suf
ficient measures to protect the product in the following locations. Insuf
ficient
protection may damage the product.
Locations where static electricity and other noise is generated.
Locations subject to strong electromagnetic or magnetic fields.
Locations subject to radioactive exposure.
Locations close to power lines.
System Design and Installation
Chapter
2
