2-3
2-1 Installation
2-1-1 External Dimensions (Unit: mm)
j AC Servo Drivers, Non-conforming Models
D R88D-UEP04H/UEP08H (200 VAC, 100, 200 W)
R88D-UEP10L (100 VAC, 100 W)
160
149
R3
Three, M4
55 130
5
4
5
45 (5) 45
6
5
(165)
149
(6)
Installation dimensions
Two, 6 dia.
D R88D-UEP12H (200 VAC, 400 W) and R88D-UEP12L (100 VAC, 200 W)
5
4
75 130 60 (5)
5
(6)
160
(165)
5
6
149
149
60
R3
Three, M4
Two, 6 dia.
Installation dimensions
System Design and Installation
Chapter
2
