42
5. Maintenance and inspection
Pull on the white label attached to the battery, and
then hold the battery with your hands to remove it.
Be careful not to drop the battery.
Insert the new battery.
(4) Reattach the metal cover and connect the connectors.
•You may hear a “pop” sound when you connect the battery if it is replaced after the unit’s operation is
stopped, but this is not abnormal.
Fit the metal cover into the grooves and slide it to the
left to secure it.
(The battery is secured inside the case.)
Connect the red and black connectors.
(Make sure that the connectors are securely
connected.)
(5) Reattach the front panel.
Fit the left side of the panel on the case, and then
attach it.
Tighten the screw with a screwdriver to secure
the front panel.
● Do not remove the battery by holding the cables.
Caution
(3) Remove the old battery, and insert the new battery.
