Omron POWLI BY75SW - C. Dimensional outline drawing

65
Reference
C. Dimensional outline drawing
BY50FW
Power cable (approx. 1.8m)
287
45
330
2.5
11
Serial communication cable (approx. 2.2m)
USB communication cable (approx. 2m)
322
298
90
Power cable (approx. 1.8m)
Serial communication cable (approx. 2.2m)
USB communication cable (approx. 2m)
BY75SW
(unit : mm / Tolerance : ±1mm)
(unit : mm / Tolerance : ±1mm)
