Standards Compliance
5
5.2 European Standards
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 189
■ DC Reactor
To comply with IEC/EN 61000-3-2, install a DC reactor to drive models4002, and 4004 when using an internal or
external EMC filter.
Table 5.6 DC Reactors for Harmonic Suppression for 400 V Class (Manufacturer: Yaskawa Electric)
Drive Model DC Reactor Model DC Reactor Rating
4002 UZDA-B 3.2 A, 28 mH
4004 UZDA-B 3.2 A, 28 mH
