Specifications
10
10.6 Drive Exterior and Mounting Dimensions
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 373
■ 4208 to 4296
Figure 10.7 Exterior and Mounting Dimensions Diagram 7
Table 10.24 400 V class (IP20)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W5
(max.)
H1 H2 H3 H4 t1 t2 d
4208
312
(12.28)
700
(27.56)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
18
(0.709)
659
(25.94)
28
(1.10)
43.5
(1.71)
28.5
(1.12)
4.5
(0.177)
4.5
(0.177)
M10
71
(156.5)
4250
312
(12.28)
700
(27.56)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
18
(0.709)
659
(25.94)
28
(1.10)
43.5
(1.71)
28.5
(1.12)
4.5
(0.177)
4.5
(0.177)
M10
71
(156.5)
4296
312
(12.28)
700
(27.56)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
18
(0.709)
659
(25.94)
28
(1.10)
43.5
(1.71)
28.5
(1.12)
4.5
(0.177)
4.5
(0.177)
M10
71
(156.5)
