Page #802 background imageLoading...
Page #802 background image
12.9 n: SPECIAL
802 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Adjust this parameter in these conditions:
If there is resonance or hunting when you use the overvoltage suppression function, increase the setting value.
If motor response is low when you use the overvoltage suppression function, decrease the setting value in 0.05-
unit increments.
n8-69 Spd Obs. P Gain Control
No.
(Hex.)
Name Description
Default
(Range)
n8-69
(065D)
Expert
Spd Obs. P Gain Control
Sets the gain that the drive uses for speed estimation. Usually it is not necessary to change this
setting.
1.00
(0.00 - 20.00)
n8-72 Spd Obs. Method Selection
No.
(Hex.)
Name Description
Default
(Range)
n8-72
(0655)
Expert
Spd Obs. Method Selection
Selects the speed estimation method. Usually it is not necessary to change this setting.
2
(1, 2)
1 : Method 1
2 : Method 2
n8-74 Light Load Iq Level
No.
(Hex.)
Name Description
Default
(Range)
n8-74
(05C3)
Expert
Light Load Iq Level
Set n8-48 [Pull-In Current (for PM Motors)] to the level of the load current (q-axis current) to be
applied.
30%
(0 - 255%)
Note:
If n8-74 > n8-75 [Mid Load Iq Level (Low)], the drive will detect oPE08 [Parameter Selection Error].
The change is linear between n8-74 and n8-75 and the level of the pull-in current from n8-48 to n8-78 [Mid Load Id Current].
n8-75 Mid Load Iq Level (Low)
No.
(Hex.)
Name Description
Default
(Range)
n8-75
(05C4)
Expert
Mid Load Iq Level (Low)
Set n8-78 [Mid Load Id Current] to the level of the load current (q-axis current) to be applied.
50%
(0 - 255%)
Note:
If n8-74 [Light Load Iq Level] > n8-75, the drive will detect oPE08 [Parameter Selection Error].
The change is linear between n8-74 and n8-75 and the level of the pull-in current from n8-48 to n8-78 [Mid Load Id Current].
n8-77 Hvy Load Iq Level
No.
(Hex.)
Name Description
Default
(Range)
n8-77
(05CE)
Expert
Hvy Load Iq Level
Set n8-49 [Heavy Load Id Current] to the level of the load current (q-axis current) to be applied.
90%
(0 - 255%)
Note:
The change is linear between n8-75 [Mid Load Iq Level (Low)] and n8-77 and the level of the pull-in current from n8-78 [Mid Load Id
Current] to n8-49 [Heavy Load Id Current].
n8-78 Mid Load Id Current
No.
(Hex.)
Name Description
Default
(Range)
n8-78
(05F4)
Expert
Mid Load Id Current
Sets the level of the pull-in current for mid-range loads.
0%
(0 - 255%)
