Omron Q2A-A4018-AAA Technical Manual

Specifications
10
10.6 Drive Exterior and Mounting Dimensions
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 375
■ 4453 to 4675
Figure 10.9 Exterior and Mounting Dimensions Diagram 9
Table 10.26 400 V class (IP20)
Model
Dimensions mm (in.)
Weigh
t
kg
(lb.)
W H D D1 D2 W1 W2 W3 W4
W5
(max.)
H1 H2 H3 H4 t1 t2 d
4453
510
(20.08)
1140
(44.88)
480
(18.90)
260
(10.24)
220
(8.66)
450
(17.72)
450
(17.72)
225
(8.86)
225
(8.86)
20
(0.787)
1093
(43.03)
25.5
(1.00)
43.5
(1.71)
30.5
(1.20)
4.5
(0.177)
4.5
(0.177)
M12
198
(436.5)
4568
510
(20.08)
1140
(44.88)
480
(18.90)
260
(10.24)
220
(8.66)
450
(17.72)
450
(17.72)
225
(8.86)
225
(8.86)
20
(0.787)
1093
(43.03)
25.5
(1.00)
43.5
(1.71)
30.5
(1.20)
4.5
(0.177)
4.5
(0.177)
M12
198
(436.5)
4675
510
(20.08)
1140
(44.88)
480
(18.90)
260
(10.24)
220
(8.66)
450
(17.72)
450
(17.72)
225
(8.86)
225
(8.86)
20
(0.787)
1093
(43.03)
25.5
(1.00)
43.5
(1.71)
30.5
(1.20)
4.5
(0.177)
4.5
(0.177)
M12
207
(456.3)
