12.7 H: TERMINALS
696 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
■ H2-61 2NO-2CM Logic Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-61
(1B47)
Expert
2NO-2CM Logic Operation
Sets the logical operation for the functions set in H2-01 [2NO-2CM Func Selection] and H2-60
[2NO-2CM 2nd Function].
1
(1 - 9)
Note:
Refer to Output of Logical Operation Results of MFDO on page 689 for more information about the relation between parameter settings
and logical operations.
■ H2-62 2NO-2CM Dly Time
No.
(Hex.)
Name Description
Default
(Range)
H2-62
(1B48)
Expert
2NO-2CM Dly Time
Sets the minimum on time used to output the logical calculation results from terminal 2NO-2CM.
0.1 s
(0.0 - 25.0 s)
■ H2-63 3NO-3CM 2nd Function
No.
(Hex.)
Name Description
Default
(Range)
H2-63
(1B49)
Expert
3NO-3CM 2nd Function
Selects the second function for terminal 3NO-3CM. The logical calculation results of the
terminals assigned to functions by H2-02 [3NO-3CM Func Selection] is output.
0
(0 - A7)
■ H2-64 3NO-3CM Logic Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-64
(1B4A)
Expert
3NO-3CM Logic Operation
Sets the logical operation for the functions set in H2-02 [3NO-3CM Func Selection] and H2-63
[3NO-3CM 2nd Function].
1
(1 - 9)
Note:
Refer to Output of Logical Operation Results of MFDO on page 689 for more information about the relation between parameter settings
and logical operations.
■ H2-65 3NO-3CM Dly Time
No.
(Hex.)
Name Description
Default
(Range)
H2-65
(1B4B)
Expert
3NO-3CM Dly Time
Sets the minimum on time used to output the logical calculation results from terminal 3NO-3CM.
0.1 s
(0.0 - 25.0 s)
■ H2-66 4NO-4CM 2nd Function
No.
(Hex.)
Name Description
Default
(Range)
H2-66
(1B4C)
Expert
4NO-4CM 2nd Function
Selects the second function for terminal 4NO-4CM. The logical calculation results of the
terminals assigned to functions by H2-03 [4NO-4CM Funct Selection] is output.
0
(0 - A7)
■ H2-67 4NO-4CM Logic Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-67
(1B4D)
Expert
4NO-4CM Logic Operation
Sets the logical operation for the functions set in H2-03 [4NO-4CM Funct Selection] and H2-66
[4NO-4CM 2nd Function].
1
(1 - 9)
Note:
Refer to Output of Logical Operation Results of MFDO on page 689 for more information about the relation between parameter settings
and logical operations.
