4-3 Wiring Conforming to EMC Directives
4
4-3-1 Peripheral Equipment Connection Examples
 Device Details
*1. Consult Soshin Electric Co., Ltd.
*2. Refer to 2-3-3 Servo Drive and Servomotor Combination Tables on page 2-17 for Servo Drive and Servomo-
tor combinations.
 Cable Details
Symbol Name Manufacturer Model Remarks
SG Surge absorber Soshin Electric
Co., Ltd.
LT-C12G801WS 1-phase 100 VAC/200 VAC
LT-C32G801WS 3-phase 200 VAC
NF Noise filter Soshin Electric
Co., Ltd.
HF2020A-SZC-33DDD
*1
1-phase 100 VAC/200 VAC (20 A)
HF3020C-SZC-33DDD
*1
3-phase 200 VAC (20 A)
OMRON R88A-FI1S103
1-phase R88D-1SN01L-ECT
1-phase R88D-1SN01H-ECT
1-phase R88D-1SN02H-ECT
R88A-FI1S105 1-phase R88D-1SN02L-ECT
1-phase R88D-1SN04H-ECT
R88A-FI1S109 1-phase R88D-1SN04L-ECT
1-phase R88D-1SN08H-ECT
R88A-FI1S202 3-phase R88D-1SN01H-ECT
3-phase R88D-1SN02H-ECT
R88A-FI1S203 3-phase R88D-1SN04H-ECT
R88A-FI1S208 3-phase R88D-1SN08H-ECT
SD Servo Drive OMRON ---
*2
SM Servomotor OMRON ---
*2
FC1 Ferrite core NEC TOKIN ESD-SR-250 ---
FC2 Ferrite core SEIWA ELEC-
TRIC MFG
E04SR301334 ---
--- I/O slave --- --- ---
--- Controller --- --- ---
No. Interface
Max. cable
length, shield
Cable classification
Ferrite
core
EN/IEC 61800-3 EN/IEC 61326-3-1
1 Power supply cable
(main circuit)
3 m
Non-shielded
Power supply port AC input power sup-
ply port
None
2 Power supply cable
(control circuit)
3 m
Non-shielded
Port for process mea-
surement and control
Signal and control
line
2 turns
4 Motor cable (Servomo-
tor)
20 m
Shielded
Power supply inter-
face
Signal and control
line
2 turns
5 EtherCAT communica-
tions cable (ECAT IN)
20 m
Shielded
Signal interface Signal and control
line
1 turn
6 EtherCAT communica-
tions cable (ECAT
OUT)
20 m
Shielded
Signal interface Signal and control
line
1 turn
7 Safety/control
I/O cables
20 m
Shielded
Signal interface Signal and control
line
None
20 m
Shielded
Signal interface Signal and control
line
None
9 Encoder cable 20 m
Shielded
Signal interface Signal and control
line
None
10 Brake interlock cable 20 m
Non-shielded
Signal interface Signal and control
line
None
