Items to Check After Unpacking
32
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
The model, rating and serial number of the 1S-series Servomotor are given on the product nameplate.
This product comes with an instruction manual.
Servomotor
Nameplate of Servomotor
Accessories of Servomotor
R88M-1M2K020T-BOS2
10150700003
200VAC 13.3 A
250 Hz
10kg
2.0 kW
2,000
Nameplate display location
From the left,
Rated rotation speed
(Example: 2,000 r/min)
Rated frequency (Example: 250 Hz)
Motor weight (Example: 10 kg)
*1
*1. The weight is not given for the Servomotor with a flange size of
80 x 80 or less.
From the left,
Number of phases (Example: 3)
Rated voltage
(Example: 200 VAC)
Rated current
(Example: 13.3 A)
Rated output
(Example: 2.0 kW)
From the left,
Insulation class (Example: F)
Totally enclosed protection
type motor (Example: TE)
Operating ambient
temperature (Example: 40°C)
Protective structure
(Example: IP67)
Motor model
Serial number
