4 Configuration and Wiring
4 - 68
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
 Countermeasure against Harmonic Current
• Use a reactor to suppress the harmonic current. A reactor can suppress a sharp change in cur-
rent.
• Select the reactor according to the model of your Servo Drive.
Reactor for Harmonic Current Reduction
Applicable Servo Drive DC Reactor
Voltage Model Model
Rated
current
Inductance
(0% to 20%)
100 VAC R88D-1SN01L-ECT R88A-PD2002 1.6 A 21.4 mH
R88D-1SN02L-ECT R88A-PD2004 3.2 A 10.7 mH
R88D-1SN04L-ECT R88A-PD2007 6.1 A 6.75 mH
200 VAC R88D-1SN01H-ECT R88A-PD2002 1.6 A 21.4 mH
R88D-1SN02H-ECT
R88D-1SN04H-ECT R88A-PD2004 3.2 A 10.7 mH
R88D-1SN08H-ECT R88A-PD2007 6.1 A 6.75 mH
R88D-1SN10H-ECT R88A-PD2015 9.3 A 3.51 mH
R88D-1SN15H-ECT
R88D-1SN20H-ECT R88A-PD2022 13.8 A 2.51 mH
R88D-1SN30H-ECT R88A-PD2037 22.3 A 1.6 mH
400 VAC R88D-1SN06F-EC R88A-PD4007 3.0 A 27 mH
R88D-1SN10F-ECT R88A-PD4015 4.7 A 14 mH
R88D-1SN15F-ECT
R88D-1SN20F-ECT R88A-PD4022 6.9 A 10.1 mH
R88D-1SN30F-ECT R88A-PD4037 11.6 A 6.4 mH
Applicable Servo Drive
DC Reactor
*1
Voltage Model Model
Rated
current
Induc-
tance
(0% to
20%)
Wire size
*2
Weight
Manufac-
turer
200 VAC R88D-1SN55H-ECT UZDA-B-OMR1S
5575H (Drawing
No. 43NA08-A)
43.7 A 0.84 mH AWG 6 to 4,
14.0 to 22.0
mm
2
5.3 kg Sao Elec-
tric Co.,
Ltd.
R88D-1SN75H-ECT
400 VAC R88D-1SN55F-ECT UZDA-BOMR1S
5575F (Drawing
No. 43NA53-B)
21.9 A 3.35 mH AWG 12 to
8, 3.5 to 8.0
mm
2
5.4 kg
R88D-1SN75F-ECT
Applicable Servo Drive
AC Reactor
*1
*1. Please contact SUN-WA TECHNOS Co., Ltd. Please inform of the Model and the Drawing No.
Voltage Model Model
Rated
current
Induc-
tance
(0% to
20%)
Wire size
*2
*2. Use wires with the rated voltage of 600 V or higher. An example of using heat-resistant polyvinyl chloride insu-
lated wires (HIV) at the ambient temperature of 50°C.
Weight
Manufac-
turer
200 VAC R88D-1SN150H-ECT UZBA-B-OMR1S
150H (Drawing
No. 43NA10-A)
70.0 A 0.35 mH AWG 6 to 4,
14.0 to 22.0
mm
2
12.2 kg Sao Elec-
tric Co.,
Ltd.
400 VAC R88D-1SN150F-ECT UZBA-B-OMR1S
150F (Drawing
No. 43NA12-A)
36.0 A 1.30 mH AWG 10 to
8, 5.5 to 8.0
mm
2
11.9 kg
