9 - 69
9 Details on Servo Parameters
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
9-7 Applied Function Objects
9
9-7-5 3B30 hex: Touch Probe 1
• Sets the Latch Function 1.
Description of Set Values
Subindex F1 hex: Setting
Set value Description
Bit 0 Enable or disable Latch Function 1
0 Disabled
1 Enabled
Bit 1 Latch 1 operation
0 Latch on the first trigger only.
1 Latch continuously on every trigger input
Bit 2 and 3 Latch 1 trigger input signal switch
00 EXT1
01 Phase Z
10 Follow the setting in the Touch probe source.
11 Reserved
Bit 4 Latch 1 trigger operation on the positive edge
0 Latch is disabled
1 Latch is enabled
To Next Page
