1 Features and System Configuration
1 - 22
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
R88D-1SN04L-ECT/-1SN08H-ECT/-1SN10H-ECT
FUSE
L1
N2
P/B1
B2
B3
U
V
W
N1
DC
FAN
CN1 CN1CN2 CN12 CN7
L2
L3
24V
DC/DC
0
N3
CNA
CNA
CNA
CNC
ECAT IN
CN10
ECAT OUT
CN11
Power
supply
Display area
rotary switch
USB
Brake
interlock
SafetyEncoderControl
interface
Gate drive
Input voltage monitoring
Voltage detection
Relay
drive
Regeneration
control
error detection
Overcurrent
detection
(IPM error)
Current detection
HS temperature
monitoring
MPU, FPGA
Control circuit
EtherCAT
communications
connector
EtherCAT
communications
connector
