AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
4510 F2 Encoder Communica-
tions Error Count Clear
00000000 to
FFFFFFFF hex
--- 0 A 4 bytes
(U32)
---
FF Clear Status --- --- --- --- 4 bytes
(U32)
---
4600 --- I/O Monitor --- --- --- --- --- ---
81 Physical I/O --- --- --- --- 4 bytes
(U32)
TxPDO
4601 --- Function Input --- --- --- --- --- ---
81 Monitor Input --- --- --- --- 4 bytes
(INT32)
---
82 Digital Inputs (Mirror
object of 60FD hex)
--- --- --- --- 4 bytes
(U32)
TxPDO
4602 --- Function Output --- --- --- --- --- ---
01 Bit Mask 00000000 to
FFFFFFFF hex
--- 00000000 hex A 4 bytes
(U32)
---
F1 Physical Outputs 00000000 to
FFFFFFFF hex
---
00000001 hex
*7
A 4 bytes
(U32)
---
4604 --- Control Input Change
Count
--- --- --- --- --- ---
81 General Input 1 --- --- 0 --- 4 bytes
(INT32)
---
82 General Input 2 --- --- 0 --- 4 bytes
(INT32)
---
83 General Input 3 --- --- 0 --- 4 bytes
(INT32)
---
84 General Input 4 --- --- 0 --- 4 bytes
(INT32)
---
85 General Input 5 --- --- 0 --- 4 bytes
(INT32)
---
86 General Input 6 --- --- 0 --- 4 bytes
(INT32)
---
87 General Input 7 --- --- 0 --- 4 bytes
(INT32)
---
88 General Input 8 --- --- 0 --- 4 bytes
(INT32)
---
F1 Count Clear 0 to 1 --- 0 A 4 bytes
(INT32)
---
FF Count Clear Execution
Status
--- --- --- --- 4 bytes
(INT32)
---
4605 --- Control Output Change
Count
--- --- --- --- --- ---
81 Error Output --- --- --- --- 4 bytes
(U32)
---
82 General Output 1 --- --- 0 --- 4 bytes
(INT32)
---
83 General Output 2 --- --- 0 --- 4 bytes
(INT32)
---
84 General Output 3 --- --- 0 --- 4 bytes
(INT32)
---
F1 Count Clear 0 to 1 --- 0 A 4 bytes
(INT32)
---
FF Count Clear Execution
Status
--- --- --- --- 4 bytes
(INT32)
---
Index
(hex)
Sub-
index
(hex)
Object name Setting range Unit Default setting
Data
attri-
bute
Size PDO map
