A - 169
Appendices
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
A-4 Sysmac Error Status Codes
A
A-4-2 Error Descriptions
Event name Absolute Encoder Counter Overflow Warning Event code 084E0000 hex
Description
The multi-rotation counter of the encoder exceeded the value set in Encoder - Absolute Encoder Counter
Overflow Warning Level (4510-02 hex).
Source
EtherCAT Master Function Mod-
ule
Source details
Slave
Detection
timing
Continuously
Error
attributes
Level
Observation
*1
*1. You can change the level to minor fault by using Warning Level Change 1 Selection (4020-05 hex).
Recovery
---
Log category
System log
Effects User program Continues. Operation Not affected.
Indicators
EtherCAT NET RUN EtherCAT NET ERR EtherCAT LINK/ACT
--- --- ---
System
-defined
variables
Variable Data type Name
None None None
Cause and
correction
Assumed cause Correction Prevention
An inappropriate value was set in
the Encoder – Operation Selec-
tion when Using Absolute
Encoder (4510-01 hex)
Set an appropriate value in the
Encoder - Operation Selection
when Using Absolute Encoder
(4510-01 hex).
Set an appropriate value in the
Encoder - Operation Selection
when Using Absolute Encoder
(4510-01 hex).
The multi-rotation number of the
encoder exceeded the warning
level
Set the travel distance so that the
multi-rotation number does not
exceed the value set in the
Encoder - Absolute Encoder
Counter Overflow Warning Level
(4510-02 hex).
Set the travel distance so that the
multi-rotation number does not
exceed the value set in the
Encoder - Absolute Encoder
Counter Overflow Warning Level
(4510-02 hex).
Attached
information
None
Precautions/
Remarks
AL status code: -, Error No.: AB00 hex
