Items to Check After Unpacking
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
 Decelerator (backlash: 3 arcminutes max.) for 1,500-r/min Servomotors
 Decelerator (backlash: 3 arcminutes max.) for 1,000-r/min Servomotors
Specifications Without key With key and tap
Servo-
motor
rated
output
Reduc-
tion
ratio
Decelerator model Model on nameplate Decelerator model Model on nameplate
4 kW
1/5
R88G-
HPG50A055K0SB
HPG-50A-05-J2EBCH R88G-
HPG50A055K0SBJ
HPG-50A-05-J6EBCH
1/11
R88G-
HPG50A115K0SB
HPG-50A-11-J2EBDH R88G-
HPG50A115K0SBJ
HPG-50A-11-J6EBDH
1/20
R88G-
HPG65A205K0SB
HPG-65A-20-J2EBCH R88G-
HPG65A205K0SBJ
HPG-65A-20-J6EBCH
1/25
R88G-
HPG65A255K0SB
HPG-65A-25-J2EBCH R88G-
HPG65A255K0SBJ
HPG-65A-25-J6EBCH
5 kW
5.5 kW
1/5
R88G-
HPG50A054K5TB
HPG-50A-05-J2EBCG R88G-
HPG50A054K5TBJ
HPG-50A-05-J6EBCG
1/12
R88G-
HPG65A127K5SB
HPG-65A-12-J2CBAI R88G-
HPG65A127K5SBJ
HPG-65A-12-J6CBAI
1/20
R88G-
HPG50A054K5TB
HPG-65A-20-J2CBAI R88G-
HPG65A204K5TBJ
HPG-65A-20-J6CBAI
Specifications Without key With key and tap
Servo-
motor
rated
output
Reduc-
tion
ratio
Decelerator model Model on nameplate Decelerator model Model on nameplate
900 W
1/5
R88G-
HPG32A05900TB
HPG-32A-05-J2PAK R88G-
HPG32A05900TBJ
HPG-32A-05-J6PAK
1/11
R88G-
HPG32A11900TB
HPG-32A-11-J2PAL R88G-
HPG32A11900TBJ
HPG-32A-11-J6PAL
1/21
R88G-
HPG50A21900TB
HPG-50A-21-J2BADB R88G-
HPG50A21900TBJ
HPG-50A-21-J6BADB
1/33
R88G-
HPG50A33900TB
HPG-50A-33-J2BADB R88G-
HPG50A33900TBJ
HPG-50A-33-J6BADB
2 kW
1/5
R88G-
HPG32A052K0TB
HPG-32A-05-J2PBS R88G-
HPG32A052K0TBJ
HPG-32A-05-J6PBS
1/11
R88G-
HPG50A112K0TB
HPG-50A-11-J2BBDH R88G-
HPG50A112K0TBJ
HPG-50A-11-J6BBDH
1/21
R88G-
HPG50A212K0TB
HPG-50A-21-J2BBDH R88G-
HPG50A212K0TBJ
HPG-50A-21-J6BBDH
1/25
R88G-
HPG65A255K0SB
HPG-65A-25-J2EBCH R88G-
HPG65A255K0SBJ
HPG-65A-25-J6EBCH
3 kW
1/5
R88G-
HPG50A055K0SB
HPG-50A-05-J2EBCH R88G-
HPG50A055K0SBJ
HPG-50A-05-J6EBCH
1/11
R88G-
HPG50A115K0SB
HPG-50A-11-J2EBDH R88G-
HPG50A115K0SBJ
HPG-50A-11-J6EBDH
1/20
R88G-
HPG65A205K0SB
HPG-65A-20-J2EBCH R88G-
HPG65A205K0SBJ
HPG-65A-20-J6EBCH
1/25
R88G-
HPG65A255K0SB
HPG-65A-25-J2EBCH R88G-
HPG65A255K0SBJ
HPG-65A-25-J6EBCH
