9-5-5 3323 hex: 3rd Notch Filter
• Sets the notch depth of the 3rd resonance suppression notch filter.
• Increasing the setting value lengthens the notch depth and the phase lag.
• Gives whether the 3rd notch filter function is enabled or disabled.
Description of Set Values
• Gives the notch frequency that is currently set in the 3rd notch filter.
• The value is updated automatically when the notch filter is specified in Adaptive Notch Filter –
Adaptive Notch Selection (3320-01 hex).
• Gives the Q-value that is currently set in the 3rd notch filter.
• The value is updated automatically when the notch filter is specified in Adaptive Notch Filter –
Adaptive Notch Selection (3320-01 hex).
• Gives the depth that is currently set in the 3rd notch filter.
• The value is updated automatically when the notch filter is specified in Adaptive Notch Filter –
Adaptive Notch Selection (3320-01 hex).
Subindex 04 hex: Depth
Subindex 81 hex: Enable Display
Set value Description
0 Disabled
1 Enabled
Subindex 82 hex: Frequency Display
Subindex 83 hex: Q-value Display
Subindex 84 hex: Depth Display
