9 Details on Servo Parameters
9 - 96
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
• Gives the load ratio of the motor.
• The value of load ratio is the average of the last five seconds.
• The value of load ratio is the ratio of the current to the rated current.
Subindex 83 hex: Motor Load Ratio
Servomotor load ratio (%) = × 100
Servomotor current
Servomotor rated current
To Next Page
