Omron R88D-1SN30F-ECT User Manual

2 Models and External Dimensions
2 - 106
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
 For 3,000-r/min Servomotors (1 to 5 kW)
Servo-
motor
rated
output
Re-
duc-
tion
ratio
Model
Outline
drawing
Dimensions [mm]
LM LR C1 C2 D1 D2 D3 D4 D5
D6
*1
E F1 F2
1 kW 1/5 R88G-HPG32A052K0B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/11 R88G-HPG32A112K0B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/21 R88G-HPG32A211K5B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/33 R88G-HPG50A332K0B 2 123 156 170 170 dia. 190 115 165 163 122 --- 103 12 53
1/45 R88G-HPG50A451K5B 2 123 156 170 170 dia. 190 115 165 163 122 --- 103 12 53
1.5 kW 1/5 R88G-HPG32A052K0B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/11 R88G-HPG32A112K0B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/21 R88G-HPG32A211K5B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/33 R88G-HPG50A332K0B 2 123 156 170 170 dia. 190 115 165 163 122 --- 103 12 53
1/45 R88G-HPG50A451K5B 2 123 156 170 170 dia. 190 115 165 163 122 --- 103 12 53
2 kW 1/5 R88G-HPG32A052K0B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/11 R88G-HPG32A112K0B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/21 R88G-HPG50A212K0B 2 123 156 170 170 dia. 190 115 165 163 122 --- 103 12 53
1/33 R88G-HPG50A332K0B 2 123 156 170 170 dia. 190 115 165 163 122 --- 103 12 53
3 kW 1/5 R88G-HPG32A053K0B 1 107 133 120 130 x 130 135 145 115 114 84 --- 98 12.5 35
1/11 R88G-HPG50A113K0B 2 123 156 170 170 dia. 190 145 165 163 122 --- 103 12 53
1/21 R88G-HPG50A213K0B 2 123 156 170 170 dia. 190 145 165 163 122 --- 103 12 53
4 kW 1/5 R88G-HPG32A054K0B 1 129 133 120 130 x 130 135 145 115 114 84 --- 98 12.5 35
1/11 R88G-HPG50A115K0B 1 149 156 170 130 x 130 190 145 165 163 122 170 103 12 53
4.7 kW
5 kW
1/5 R88G-HPG50A055K0B 1 149 156 170 130 x 130 190 145 165 163 122 170 103 12 53
1/11 R88G-HPG50A115K0B 1 149 156 170 130 x 130 190 145 165 163 122 170 103 12 53
