3 Specifications
3 - 6
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
200-VAC Input Models
Servo Drive model (R88D-) 1SN01H-ECT 1SN02H-ECT 1SN04H-ECT 1SN08H-ECT
Item 100 W 200 W 400 W 750 W
Input Main circuit Power sup-
ply voltage
Single-phase and 3-phase 200 to 240 VAC (170 to 252 V)
*1
Rise time 500 ms max.
*2
Frequency
50/60 Hz (47.5 to 63 Hz)
*1
Control circuit Power sup-
ply voltage
24 VDC (21.6 to 26.4 V)
Current con-
sumption
*3
600 mA
Rated current
[A (rms)]
(Main circuit
power supply
voltage: 240
VAC)
Single-
phase
1.8 2.7 4.6 7.3
3-phase 1.0 1.5 2.7 4.0
Out-
put
Rated current [A (rms)] 0.8 1.5 2.5 4.6
Maximum current [A (rms)] 3.1 5.6 9.1 16.9
Heating value [W] Main cir-
cuit
*5
15.7/15.3
*5
15.2/14.6
*5
22.4/22.4
*5
40/39.7
*5
Control cir-
cuit
11 11 11 13.2
Applicable Servomotor rated output
[W]
100 200 400 750
3,000-r/min Servomo-
tor (R88M-)
Batteryless
23-bit ABS
1M05030T
1M10030T
1M20030T 1M40030T 1M75030T
2,000-r/min Servomo-
tor (R88M-)
Batteryless
23-bit ABS
--- --- --- ---
1,000-r/min Servomo-
tor (R88M-)
Batteryless
23-bit ABS
--- --- --- ---
Hold time at momentary power inter-
ruption (Main circuit power supply
voltage: 200 VAC)
10 ms (Load condition: rated output)
*6
Weight [kg] 1.2 1.2 1.5 2.0
