Omron R88D-1SN30F-ECT User Manual

3 - 29
3 Specifications
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
3-1 Servo Drive Specifications
3
3-1-5 Control I/O Connector (CN1) Specifications
Control I/O Connector (40 pins)
Model Manufacturer OMRON model
DFMC1,5/20-ST-3,5-LRBKBDMC-21 PHOENIX CONTACT
R88A-CN101C
*1
*1. Four short-circuit wires are connected to the connector.
121
Applicable wire: AWG 24 to 16 (0.2 to 1.5 mm
2
) (Strip length of the wire insulating
cover: 10 mm)
