3 Specifications
3 - 40
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
• 750 W • 900 W, 1 kW
• 1.5 kW • 2 kW
• 3 kW • 4 kW
Detection time [s]
Output current ratio [%]
100%
150% 200% 250% 300% 350% 400%
0.1
10
1
100
1000
10000
1L1K030T (rotation)
1L1K030T (lock)
1M1K020T (rotation)
1M1K020T (lock)
1M90010T (rotation)
1M90010T (lock)
R88M-1L1K030T/-1M1K020T/-1M90010T
0.31 s
Detection time [s]
Output current ratio [%]
100%
150% 200% 250% 300% 350% 400%
0.1
10
1
100
1000
10000
S,BS (rotation)
S,BS (lock)
OS,BOS (rotation)
OS,BOS (lock)
R88M-1M75030T
Detection time [s]
Output current ratio [%]
100%
150% 200% 250% 300% 350% 400%
0.1
10
1
100
1000
10000
1L2K030T (rotation)
1L2K030T (lock)
1M2K020T (rotation)
1M2K020T (lock)
1M2K010T (rotation)
1M2K010T (lock)
R88M-1L2K030T/-1M2K020T/-1M2K010T
Detection time [s]
Output current ratio [%]
100%
150% 200% 250% 300% 350% 400%
0.1
10
1
100
1000
10000
1L1K530T (rotation)
1M1K520T (rotation)
1L1K530T (lock)
1M1K520T (lock)
R88M-1L1K530T/-1M1K520T
Detection time [s]
Output current ratio [%]
100%
150% 200% 250% 300% 350% 400%
0.1
10
1
100
1000
10000
1L3K030T (rotation)
1L3K030T (lock)
1M3K020T (rotation)
1M3K020T (lock)
1M3K010T (rotation)
1M3K010T (lock)
R88M-1L3K030T/-1M3K020T/-1M3K010T
Output current ratio [%]
Detection time [s]
1L4K030T (rotation)
1L4K030T (lock)
1M4K015T (rotation)
1M4K015T (lock)
R88M-1L4K030T/-1M4K015T
100%
150% 200% 250% 300% 350% 400%
0.1
10
100
1000
10000
1
