3 Specifications
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
3-4 Cable and Connector Specifications
3
3-4-4 Resistance to Bending of Flexible Cable
 Power Cables without Brake Wire
 Power Cables with Brake Wire
 Extension Cable
Model
Bend test conditions
Estimated life
Minimum bending
radius [R]
Stroke
R88A-CA1ASF
*1
*1.  represents a number between 003 and 050.
40 mm 500 mm 10 million times
R88A-CA1ASFR
*2
*2.  represents a number between 003 and 020.
40 mm 500 mm 10 million times
R88A-CA1BSF
*1
R88A-CA1CSF
*1
90 mm 500 to 1,000 mm 20 million times
R88A-CA1ESF
*1
90 mm 500 to 1,000 mm 20 million times
R88A-CA1FSF
*1
100 mm 500 to 1,000 mm 20 million times
R88A-CA1HSF
*2
150 mm 500 to 1,000 mm 10 million times
R88A-CA1JSF
*2
173 mm 500 to 1,000 mm 10 million times
R88A-CA1KSF
*2
232 mm 500 to 1,000 mm 10 million times
Model
Bend test conditions
Estimated life
Minimum bending
radius [R]
Stroke
R88A-CA1BBF
*1
R88A-CA1CBF
*1
R88A-CA1DBF
*1
*1.  represents a number between 003 and 050.
*2.  represents a number between 003 and 020.
90 mm 500 to 1,000 mm 20 million times
R88A-CA1EBF
*1
90 mm 500 to 1,000 mm 20 million times
R88A-CA1FBF
*1
100 mm 500 to 1,000 mm 20 million times
R88A-CA1HBF
*2
150 mm 500 to 1,000 mm 10 million times
R88A-CA1JBF
*2
173 mm 500 to 1,000 mm 10 million times
R88A-CA1KBF
*2
232 mm 500 to 1,000 mm 10 million times
Model
Bend test conditions
Estimated life
Minimum bending
radius [R]
Stroke
R88A-CA1HEBF
*1
*1.  represents a number between 003 and 050.
150 mm 500 to 1,000 mm 10 million times
R88A-CA1JEBF
*1
173 mm 500 to 1,000 mm 10 million times
R88A-CA1KEBF
*1
232 mm 500 to 1,000 mm 10 million times
