Name: Omron R88D-1SN30F-ECT
Brand: Omron
Rating: 4 (1 reviews)

To Next Page

To Previous Page

4 - 61

4 Configuration and Wiring

AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)

4-3 Wiring Conforming to EMC Directives

4-3-1 Peripheral Equipment Connection Examples

HF3080C-SZC-47EDE/ HF3100C-SZC-33EDE

 Circuit Diagram of Book-type Noise Filter

For single-phase

For 3-phase

(17.5)

(20.5)

6.5

(20.5)

290

310

100

6.5 dia.

210

LOADLINE

(PE)

LOADLINE

(PE)
