1 - 11
1 Features and System Configuration
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
1-3 Names and Functions
1
1-3-1 Servo Drive Part Names
Motor connector
(CNC)
Bottom view
Encoder connector
(CN2)
Brake interlock
connector (CN12)
Main circuit connector E
(CNE)
terminal
terminal
Screw for mounting
shield clamp
(2 places)
