Omron R88D-1SN30F-ECT User Manual

1 - 13
1 Features and System Configuration
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
1-3 Names and Functions
1
1-3-1 Servo Drive Part Names
R88D-1SN150F-ECT
Charge lamp
Control power
supply connector
(CND)
Main circuit terminal
block(CNA)
Main circuit
connectorB
(CNB)
Control I/O
connector(CN1)
Status
indicators
7-segment LED
display
ID switches
terminal
Status
indicators
EtherCAT
communications
connector(ECAT IN
CN10)
EtherCAT
communications
connector
(ECAT OUT CN11)
USB connector
Motor terminal
block(CNC)
Brake interlock
connector(CN12)
Screw for mounting
shield clamp (2 places)
terminal
Main circuit
connector E
(CNE)
Encoder connector(CN2)
terminal
