2-26
2-4 External and Mounting Dimensions
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
2
Models and External Dimensions
3-phase 200 VAC: R88D-KN20H-ECT-R (2 kW)
Wall Mounting
External dimensions Mounting dimensions
Front Mounting (Using Front Mounting Brackets)
External dimensions Mounting dimensions
86
85
5017.5
42.5
5.2
5.2
φ5.2
R2.6 R2.6
195
70
198 188 168
17.5
50
5.25.2
42.5
φ5.2
R2.6
R2.6
1.8
25
188
50
17.5
φ5.2
168
86
86
85
5017.5
42.5
5.2
5.2
198 188 168
φ5.2
R2.6
R2.6
195
30.7
2.5
70
17.5
50
5.25.2
42.5
φ5.2
R2.6
R2.6
2.5
25
188
50
17.5
φ5.2
(88)*
(176)*
* Rectangular hole dimensions are reference values.
Rectangular
hole
