2-4 External and Mounting Dimensions
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
2
Models and External Dimensions
3-phase 200 VAC: R88D-KN30H-ECT-R/-KN50H-ECT-R (3 to 5 kW)
Wall Mounting
External dimensions Mounting dimensions
Front Mounting (Using Front Mounting Brackets)
External dimensions Mounting dimensions
R2.6
R2.6
φ5.2
R2.6R2.6
φ5.2
130
100
15
65
5.2
5.2
220 240 250
5.2
5.2
65
100
15
214
70
3.5
φ5.2
50
240
100
130
15
220
R2.6
R2.6
φ5.2
R2.6R2.6
φ5.2
130
100
15
65
5.2
5.2
220 240 250
5.2
5.2
65
100
15
214
40.7
2.5
2.5
70
φ5.2
50
240
100
(132)*
15
(228)*
Rectangular
hole
* Rectangular hole dimensions
are reference values.
