4 System Design
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
4-4 Noise Reduction
4
4-4-2 Selecting Connection Components
• Use twisted-pair cables for the power supply cables, or bind the cables.
z External Dimensions
SUP-EK5-ER-6 3SUP-HU10-ER-6
3SUP-HU30-ER-6
L1C
L1
L2
L3
L2C
Twisted-pair cables Bound cables
Servo Drive Servo Drive
Binding
88.0
100±2.0 53.1±2.0
5.0
2-
Ø
4.5×6.75
2-
Ø
4.5
6-M4
50.0
60.0
12.0
10.0
11.6
13.0
75.07.0
2.0
105
115
5.5
43
7052
10
95
M4
M3
M4
Ground terminal
Attachment
screw for cover
Cover
Noise filter
unit
135
145
5.5
50
7052
10
125
M4
Ground
terminal M4
Attachment screw
for cover M3
Cover
Noise filter unit
