G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
Event name Phase-A Connection Error Event code 0814 0000 hex
Description An error such as broken wiring was detected in the external encoder phase-A connection.
Source
EtherCAT Master Function Module
Source
details
Slave Detection
timing
Continuously
Error
attributes
Level
Minor fault
Recovery
Error reset
(after cycling slave
power)
Log category
System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators
EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
–––
System
-defined
variables
Variable Data type Name
None – –
Cause and
correction
Assumed cause Correction Prevention
An error such as broken wiring
was detected in the external
encoder phase-A connection.
Wire phase A of the external
encoder correctly as shown in the
wiring diagram. If the cable is
broken, replace it.
Wire phase A of the external
encoder correctly as shown in the
wiring diagram.
Attached
information
None
Precautions/
Remarks
“55” is displayed on the Servo Drive front panel and F055 is given as the AlarmCode (4001 hex).
Event name Phase-B Connection Error Event code 0815 0000 hex
Description An error such as broken wiring was detected in the external encoder phase-B connection.
Source
EtherCAT Master Function Module
Source
details
Slave Detection
timing
Continuously
Error
attributes
Level
Minor fault
Recovery
Error reset
(after cycling slave
power)
Log category
System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators
EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
–––
System
-defined
variables
Variable Data type Name
None – –
Cause and
correction
Assumed cause Correction Prevention
An error such as broken wiring
was detected in the external
encoder phase-B connection.
Wire phase B of the external
encoder correctly as shown in the
wiring diagram. If the cable is
broken, replace it.
Wire phase B of the external
encoder correctly as shown in the
wiring diagram.
Attached
information
None
Precautions/
Remarks
“55” is displayed on the Servo Drive front panel and F155 is given as the AlarmCode (4001 hex).
