9-5 Interface Monitor Settings
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
9
Details on Servo Parameter Objects
Sequence I/O Signals on page 7-1.
Set the function and logic for general-purpose input 7 (IN7).
Refer to the Details of Control Inputs in Control Input Details on page 3-17, as well as 7-1
Sequence I/O Signals on page 7-1.
Set the function and logic for general-purpose input 8 (IN8).
Refer to the Details of Control Inputs in Control Input Details on page 3-17, as well as 7-1
Sequence I/O Signals on page 7-1.
Set the function assignment for general-purpose output 1 (OUTM1).
Refer to the Details of Control Inputs in Control Output Details on page 3-20, as well as 7-1
Sequence I/O Signals on page 7-1.
Set the function assignment for general-purpose output 2 (OUTM2).
Refer to the Details of Control Inputs in Control Output Details on page 3-20, as well as 7-1
Sequence I/O Signals on page 7-1.
3406 hex
Input Signal Selection 7
Setting
range
0 to 00FF FFFF hex Unit −
Default
setting
0020 2020
hex
Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
All
3407 hex
Input Signal Selection 8
Setting
range
0 to 00FF FFFF hex Unit −
Default
setting
002E 2E2E
hex
Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
All
3410 hex
Output Signal Selection 1
Setting
range
0 to 00FF FFFF hex Unit −
Default
setting
0003 0303
hex
Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
All
3411 hex
Output Signal Selection 2
Setting
range
0 to 00FF FFFF hex Unit −
Default
setting
0002 0202
hex
Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
All
