Switch Mode Power Supply S82J 13
Dimensions with Mounting Brackets (Provided)
150±0.5
50±0.5
150±0.5
100±0.5
S82J-60024@ (600 W)
Four, M4 holes (depth: 8 max. on one side)
Nine, M4 terminal screws
Side Mounting
Bottom Mounting
Four, 4.5 dia.
Four, 4.5 dia.
Mounting Holes
(Surface Screw Mounting)
Eight, M4 holes
(depth: 8 max.
on both sides)
Four, M4 holes
(depth: 8 max.)
(b)
(b)
(a)
(a)
1.5
11
9
60
5
20
31.5
15
20.5
4.7
4.6
11
74
15±0.2
4.6
60
20
t=1.0
Material: Stainless steel
Mounting bracket
Power supply unit
For 10-/25-/50-/100 (24 V)-W Models
Mounting Holes Using the Mounting Bracket
Note: The mounting screws must be ordered separately.
Two, M3
Two,
3.5 dia.
Attach the mounting bracket to the panel and
loosely tighten the two screws. Insert the projected
parts of the bracket (b) to the square holes of the
power supply (a). Then securely tighten the screws.
Front-mounting Bracket (Provided)
30±0.5
110±0.5
38
1.5
6.5
11
t=0.8
23.5
Mounting bracket
120 max.
Two, 5 dia.
For 100- (5, 12, 15 V) and 150-W Models
Attaching the Mounting Brackets
Note: The brackets are for front-mounting.
5 dia.
Front-mounting Bracket (Provided)
Dimensions with Mounting Brackets
