Omron S82J Series Product Manual

2 Switch Mode Power Supply S82J
Ordering Information
■ List of Models
Note: For details on normal stock models, contact your nearest OMRON representative.
Front-mounting Bracket Type
Configuration Input Voltage Power ratings Output voltage Output current Front-mounting bracket
types
(Front terminals)
Open-frame type 100 to 240 VAC (free) 10 W 5 V 2 A S82J-01005A
12 V 1 A S82J-01012A
15 V 0.7 A S82J-01015A
24 V 0.5 A S82J-01024A
25 W 5 V 5 A S82J-02505A
12 V 2.1 A S82J-02512A
15 V 1.7 A S82J-02515A
24 V 1.1 A S82J-02524A
50 W 5 V 10 A S82J-05005A
12 V 4.2 A S82J-05012A
24 V 2.1 A S82J-05024A
100 or 200 VAC
(selected automatically)
100 W 5 V 20 A S82J-10005A
12 V 8.5 A S82J-10012A
15 V 7 A S82J-10015A
100 to 240 VAC (free) 24 V 4.5 A S82J-10024A
100 or 200 VAC
(selected automatically)
150 W 24 V 6.5 A S82J-15024A
Covered type 100 to 240 VAC (free) 10 W 5 V 2 A S82J-01005D
12 V 1 A S82J-01012D
15 V 0.7 A S82J-01015D
24 V 0.5 A S82J-01024D
25 W 5 V 5 A S82J-02505D
12 V 2.1 A S82J-02512D
15 V 1.7 A S82J-02515D
24 V 1.1 A S82J-02524D
50 W 5 V 10 A S82J-05005D
12 V 4.2 A S82J-05012D
24 V 2.1 A S82J-05024D
100 or 200 VAC
(selected automatically)
100 W 5 V 20 A S82J-10005D
12 V 8.5 A S82J-10012D
15 V 7 A S82J-10015D
100 to 240 VAC (free) 24 V 4.5 A S82J-10024D
100 or 200 VAC (selected
automatically)
150 W 24 V 6.5 A S82J-15024D
100 or 200 VAC (selectable) 300 W 24 V 14 A S82J-30024
S82J-30024N
600 W 27 A S82J-60024
S82J-60024N
