14 Switch Mode Power Supply S82J
300-W and 600-W Models
Note: A mounting bracket is included with the S82J-30024 and S82J-60024, but not with the S82J-30024N and S82J-60024N.
Front-mounting Bracket
For 300-W Models (S82Y-J30F)
Note: To provide ventilation
space, the body will shift
forward by 21.6 mm from
the mounting surface.
Note: To provide ventilation space,
the body will shift forward by
23.6 mm from the mounting
surface.
48
t=1.6
15
30
7.5 7.5
160
145±
0.5
R2.5
10 dia.
32
36.4±
0.2
92
Four, 5 dia.
145±
0.5
90±
0.5
Four, M4
N
L
145±
0.5
140±
0.5
Four, M4
Note: Mounting Brackets are provided
in a set, one for the right side
and one for the left side.
Dimensions with Mounting Brackets
For 300-W Models
Dimensions with Mounting Brackets
For 600-W Models
Attaching the Mounting Brackets
For 300-W Models
Attaching the Mounting Brackets
For 600-W Models
