6 Switch Mode Power Supply S82J
+V
−V
DC Output
Input
Fuse*
Noise filter
Overvoltage protection circuit (5 V only)
Photocoupler
* Fuse capacity: 5 A
S82J-100@@@@
(100 W, 5-/12-/15-V Output)
Inrush current
protection circuit
Rectification and
smoothing circuit
Over-
voltage
detector
AC (L)
AC (N)
Detection
circuit
Rectification
and smooth-
ing circuit
Noise filter
Control circuit
Overcur-
rent de-
tection
circuit
100 or 200 V
(selected auto-
matically)
AC(L)
AC(N)
+V
−V
+V
−V
AC (L)
AC (N)
Input
Fuse (5 A)
Noise filter
Control circuit
Photocoupler
Detection
circuit
DC Output
S82J-10024@@ (100 W, 24-V Output)
Rectification
Photocoupler
DC Output
Input
Fuse (8 A)
Noise filter
Rectification
Control circuit
Photocoupler
S82J-15024@@ (150 W)
Inrush current
protection
circuit
Smoothing
circuit
Rectification
and
smoothing
circuit
Overvoltage
detection
circuit
Inrush current
protection circuit
100 or 200 V
(selected au-
tomatically)
Overcurrent
detection
circuit
Rectification
and
smoothing
circuit
Detection
circuit
Overcurrent
detection
circuit
