Omron S82K-00305

New S82K
New S82K
17
Dimensions
Note:
All units are in millimeters unless otherwise indicated.
S82K-003
jj
(3 W)
S82K-007
jj
(7.5 W)
M3.5 with square washer
(sliding
7max.)
Mounting Holes
Attached
Mounting
Bracket
M4 or 4.5-dia.
hole
Note:
If more than one Power Supply is installed in a
row,keepadistanceof20mmmin.(L=20mm
min.) between each adjacent Power Supply.
Mounting Brackets
(Supplied with the Switching Power Supply)
Used when not mounting the Power Supply directly
on the DIN track.
Two, 4.5
!
0.1
dia.
35
!
0.15
25
!
0.15
37.5
!
0.1
27
!
0.1
S82K-015
jj
(15 W)
Mounting Holes
Note:
If more than one Power Supply is installed in a row, keep
a distance of 20 mm min. (L = 20 mm min.) between each
adjacent Power Supply.
Two, M4 or 4.5-dia. mounting holes
60
L
35
75 58.1
4.6
(sliding 7 max.)
M3.5 with square
washer
45
9.8 8.3
45
91 5
35
7.5
