10 Switch Mode Power Supply S82K
Dimensions
Note: All units are in millimeters unless otherwise indicated.
35±0.15
25±0.15
37.5±0.1
27±0.1
M3.5 with square washer
Mounting Holes
Two, 4 . 5 ±0.1 dia.
S82K-003@@ (3 W)
S82K-007@@ (7.5 W)
(sliding
7 max.)
Note: If more than one Power Supply is installed in a
row, keep a distance of 20 mm min. (L = 20 mm
min.) between each adjacent Power Supply.
Mounting Brackets (Included)
(Supplied with the Switching Power Supply)
Used when not mounting the Power Supply directly
on the DIN rail.
Attached
Mounting
Bracket
M4 or 4.5-dia.
hole
75 58.1
45
9.8
8.3
45
91
5
35
7.5
60
L
35
S82K-015@@ (15 W)
Mounting Holes
Two, M4 or 4.5-dia. mounting holes
4.6
(sliding 7 max.)
M3.5 with square
washer
Note: If more than one Power Supply is installed in a row,
keep a distance of 20 mm min. (L = 20 mm min.)
between each adjacent Power Supply.
To Next Page
