Omron S82K

2 Switch Mode Power Supply S82K
Specifications
■ Ratings/Characteristics
Note:1. When a load is connected that has a built-in DC-DC converter, the overload protection may operate at startup and the power supply may not start.
Refer to the Overload Protection section on page 8 for details.
2. Use with DC voltage input is beyond the conditions of approval or conformance to applicable safety standards. (DC input possible with 15 W max.
Use the 7.5-W single-output models under the load of 90% max. if the voltage range is between 90 and 110 VDC.
Do not use the Inverter output for the Power supply. Inverters with an output frequency of 50/60 Hz are available, but the rise in the internal temperature of the
Power Supply may result in ignition or burning.
3. Defined with a 100% load and the rated input voltage (100 or 200 VAC.)
4. The output specification is defined at the power supply output terminals.
5. If the V. ADJ adjuster is turned, the voltage will increase by more than +10% of the voltage adjustment range. (+15% for S82K-03012/-03024)
When adjusting the output voltage, confirm the actual output voltage from the Power Supply and be sure that the load is not damaged.
6. The settings for the output voltage must be within the following range:
+V: ±1% of the rated value
−V: ±5% of the rated value
7. Refer to the Overload Protection section on page 8 for details.
8. When using the 7.5-W single-output models within the input voltage range between 90 and 110 VDC, the protection function will operate at a current of 95% to
160% of the rated load current.
Power ratings
(See note 1.)
S82K
Single output Dual output Single output
Item 3 W 7.5 W 7.5 W 15 W 30 W
Efficiency (typical) 60% min. (Varies depending
on specifications)
64% min. (Varies depending on specifications) 66% min. (Varies depending on specifications)
Input Voltage
(See note 2.)
AC 100 to 240 VAC (85 to 264 VAC)
DC 90 to 350 VDC Not possible
Frequency 50/60 Hz (47 to 450 Hz)
Current
(See note 3.)
100-V input 0.15 A max. 0.25 A max. 0.45 A max. 0.9 A max.
200-V input 0.25 A max. 0.6 A max.
Power Factor ---
Harmonic current emissions ---
Leakage current
(See note 3.)
100-V input 0.5 mA max.
200-V input 1 mA max.
Inrush current
(See note 3.)
100-V input 15 A max. (for cold start at 25°C)
25 A max. (for cold start at 25°C)
200-V input 30 A max. (for cold start at 25°C)
50 A max. (for cold start at 25°C)
Noise filter Ye s
Out-
put
(See
note
4.)
Voltage Adjustment Range ±10% (with V. ADJ) (See note 5.) Not possible (See note 6.) ±10% (with V. ADJ) (−10% to 15% for S82K-03012/-03024)
(See note 5.)
Ripple (See note 3.) 2% (p-p) max.
Input variation influence 0.5% max. (at 85 to 264 VAC input, 100% load)
Load variation influence
(rated input voltage)
1.5% max. (0 to 100% load) +V: 1.5% max.
−V: 3% max. (0 to 100% load)
1.5% max. (0 to 100% load)
Temperature variation influ-
ence (See note 3.)
0.05%/°C max.
Start up time 100 ms max. (up to 90% of output voltage at rated input and output)
Hold time (See note 3.) 20 ms min.
Addi-
tion-
al
func-
tions
Overload protection
(See note 7.)
105% to 160% of rated load current (105% to 250% of rated load current for dual output models), gradual current/voltage
drop, automatic reset (See note 8.)
105% to 160% of rated load
current, gradual current in-
crease, voltage drop intermit-
tent operation, automatic reset
Overvoltage protection No
Undervoltage alarm indica-
tion
Yes (color: red)
Undervoltage alarm output No
Parallel operation No
Oth-
er
Operating ambient tempera-
ture
Refer to the derating curve in Engineering Data. (with no icing or condensation)
Storage temperature −25 to 65°C (with no icing or condensation)
Operating ambient humidity 25°C to 85% (Storage humidity: 25% to 90%)
Dielectric strength 3.0 kVAC for 1 min. (between all inputs and all outputs)
2.0 kVAC for 1 min. (between all inputs and PE terminals)
1.0 kVAC for 1 min. (between all outputs and PE terminals)
Detection
current
10 mA 20 mA
Insulation resistance 100 MΩ min. (between all outputs and all inputs, PE terminals) at 500 VDC
Vibration resistance 10 to 55 Hz, 0.375-mm single amplitude for 2 h each in X, Y, and Z directions
Shock resistance
300 m/s
2
, 3 times each in ±X, ±Y, ±Z directions
Output indicator Yes (color: green)
EMI Conducted
Emissions
Conforms to EN61204-3 EN55011 Class B and based on FCC Class B
Radiated
Emissions
Conforms to EN61204-3 EN55011 Class B
EMS Conforms to EN61204-3 High severity levels
Approved standards UL: UL508 (Listing), 60950-1 Class 2 (excluding Dual output models)
CSA: cUL: C22.2 No.14, cUR: No. 60950-1 Class 2 (excluding Dual output models)
EN/VDE: EN50178 (VDE=0160), EN60950-1 (=VDE0805 Teil 1)
Based on VE0106/P100
Weight 150 g max. 260 g max. 380 g max.
