Omron S8JX-G Series

S8JX
26
S8JX-G
S8JX-P
Common Precautions
Mounting Bracket Provided with Front-mounting Power Supplies a
15-/35-/50-/100-/150-W Models
S82Y-J00F Front-mounting
Bracket
Front-mounting Method
Temporarily attach the enclosed mounting
bracket as shown in the illustration on the right,
hook the holes (parts a) in the Power Supply on
hooks on the mounting bracket (parts b), and
secure the Power Supply with two mounting
screws.
300-/600-W Models
Front-mounting Bracket (S82Y-J30F)
Dimensions with
Mounting Brackets
Attaching the Mounting Brackets
Dimensions
Mounting
dimensions
11
9
1.5
60
11
20
5
31.5
20.5
15
4.7
4.6
4.6 15
±0.2
74
Two, 3.5 dia.
t = 1.0
Material: Stainless steel
Two, M3
20
60
b
b
a
a
Power Supply
Mounting bracket
Note: Mounting screws are
not provided.
48
15
30
7.5 7.5
160
32
±0.2
92
145
±0.3
R2.5
10 dia.
Two, 5 dia.
t = 1.6
Note: Mounting Brackets are provided in a set, one
for the right side and one for the left side.
145
±0.3
80
±0.5
Four, M4
300-W Model
300-W Model
Note: To provide ventilation space, the body
will shift forward by 21.6 mm from the
mounting surface.
145
±0.3
120
±0.5
Four, M4
600-W Model 600-W Model
Note: To provide ventilation space, the body
will shift forward by 23.6 mm from the
mounting surface.
