6-3
Three
Model 3G3EV- --- A4002(-j) A4004(-j)
A4007(-j) A4015(-j)
Three
phase,
400 VAC
Power
supply
Rated voltage
and frequency
Three-phase, 380 to 460 VAC, 50/60 Hz
supply
Allowable
voltage
fluctuation
–15% to 10 %
Allowable
frequency
fluctuation
±5%
Heating value (W) --- 25.5 34.7 56.0 78.5
Weight (kg) --- 1.0 1.0 1.5 2.0
Maximum applicable motor capacity
(kW)
--- 0.2 (0.37) 0.4 (0.55) 0.75 (1.1) 1.5 (1.5)
Output
specifi-
Rated output capacity
(kVA)
--- 0.9 1.4 2.6 3.7
specifi-
cations
Rated output current (A) --- 1.2 1.8 3.4 4.8
Rated output voltage Three-phase, 380 to 460 VAC
(Corresponds to the input voltage)
Maximum output
frequency
400 Hz (Parameter setting)
Cooling method Self-cooling
H General Specifications
Installation type Panel mounting
Installation site Indoor (free from corrosive gases and dust)
Ambient temperature for
operation
–10° to 50°C
Humidity 90% or less (no-condensing)
Ambient temperature for storage –20° to 60°C
Altitude 1,000 m max.
Vibration resistance Less than 20 Hz: 9.8 m/s
2
or less
20 to 50 Hz: 1.96 m/s
2
or less
Cable length between Inverter
and motor
100 m max.
Specifications Chapter 6
