512
E5ZE Temperature Controller Read Protocol Appendix H
Read Alarm Temperatures (Sequence No. 108 (Hex 006C))
Reads the alarm temperatures and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
`
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0021 (0033 decimal)
+1 Channel 0
Alarm 1 set value (rightmost 4 digits)
(4 digits BCD)
0000 to 9999
F indicates a negative number.
+2 Channel 0
Alarm 1 set value (leftmost 1 digit)
(4 digits BCD)
0000 to 0009
F indicates a negative number.
+3 Channel 0
Alarm 2 set value (rightmost 4 digits)
(4 digits BCD)
0000 to 9999
F indicates a negative number.
+4 Channel 0
Alarm 2 set value (leftmost 1 digit)
(4 digits BCD)
0000 to 0009
F indicates a negative number.
•
•
•
+29 Channel 7
Alarm 1 set value (rightmost 4 digits)
(4 digits BCD)
0000 to 9999
F indicates a negative number.
+30 Channel 7
Alarm 1 set value (leftmost 1 digit)
(4 digits BCD)
0000 to 0009
F indicates a negative number.
+31 Channel 7
Alarm 2 set value (rightmost 4 digits)
(4 digits BCD)
0000 to 9999
F indicates a negative number.
+32 Channel 07
Alarm 2 set value (leftmost 1 digit)
(4 digits BCD)
0000 to 0009
F indicates a negative number.
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
Receive data
storage words
Number of receive data words
+0
+1
+2
+3
+4
+29
+30
+31
+32
Alarm 1 set value (rightmost 4 digits)
~ ~
Alarm 1 set value (leftmost 1 digit)
Alarm 1 set value (rightmost 4 digits)
Alarm 1 set value (rightmost 1 digit)
Channel 0
Channel 7
Alarm 2 set value (rightmost 4 digits)
Alarm 2 set value (leftmost 1 digit)
Alarm 2 set value (rightmost 4 digits)
Alarm 2 set value (leftmost 1 digit)
