Omron SYSMAC CJ1W-SCU21-V1 User Manual

513
E5ZE Temperature Controller Read Protocol Appendix H
Read Hysteresis (Sequence No. 109 (Hex 006D))
Reads the hysteresis and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Read Operation Status (Sequence No. 110 (Hex 006E))
Reads the operation status of the E5ZE and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0011 (0017 decimal)
+1 Channel 0
Hysteresis (4 digits BCD)
0000 to 0999
+2 Channel 0
Cooling hysteresis (4 digits BCD)
0000 to 0999
•
•
•
+15 Channel 7
Hysteresis (4 digits BCD)
0000 to 0999
+16 Channel 7
Cooling hysteresis (4 digits BCD)
0000 to 0999
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
Receive data
storage words
Number of receive data words
+0
+1
+2
+3
+4
+15
+16
Hysteresis
~ ~
Cooling hysteresis
Hysteresis
Cooling hysteresis
Channel 0
Channel 7
Hysteresis
Cooling hysteresis
Channel 1
First word of
send data
Number of send data words+0
+1 (Undefined) Unit No.
