E5ZE Temperature Controller Write Protocol Appendix I
Write Control Period (Sequence No. 153 (Hex 0099))
Writes the control periods and cooling control periods.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0012 (0018 decimal) (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel 0
Control period (4 digits BCD)
0001 to 0099
+3 Channel 0
Cooling control period
(4 digits BCD)
0001 to 0099
+4 Channel 1
Control period (4 digits BCD)
0001 to 0099
+5 Channel 1
Cooling control period
(4 digits BCD)
0001 to 0099
•
•
•
+16 Channel 7
Control period (4 digits BCD)
0001 to 0099
+17 Channel 7
Cooling control period
(4 digits BCD)
0001 to 0099
First word of
send data
Number of send data words+0
+1
+2
+3
+4
+5
+16
+17
(Undefined) Unit No.
Control period
~ ~
Cooling control period
Control period
Cooling control period
Channel 0
Channel 7
Control period
Cooling control period
Channel 1
