Omron SYSMAC CJ1W-SCU21-V1 User Manual

528
E5ZE Temperature Controller Write Protocol Appendix I
Write Output Mode (Sequence No. 154 (Hex 009A))
Writes the output mode (normal/reverse).
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Alarm Mode (Sequence No. 155 (Hex 009B))
Writes the alarm modes for alarm 1 and alarm 2.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0003 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Write code (2 digits Hex) 00 to FF
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0012 (0018 decimal) (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel 0
Alarm 1 set code (2 digits Hex)
00 to 0C
+3 Channel 0
Alarm 2 set code (2 digits Hex)
00 to 0C
+4 Channel 1
Alarm 1 set code (2 digits Hex)
00 to 0C
+5 Channel 1
Alarm 2 set code (2 digits Hex)
00 to 0C
•
•
•
+16 Channel 7
Alarm 1 set code (2 digits Hex)
00 to 0C
+17 Channel 7
Alarm 2 set code (2 digits Hex)
00 to 0C
First word of
send data
Number of send data words
+0
+1
+2
(Undefined)
Unit No.
(Undefined)
Write code
First word of
send data
Number of send data words
+0
+1
+2
+3
+4
+5
+16
+17
(Undefined)
Unit No.
Alarm 1 set code
(Undefined)
~ ~
Channel 0
Channel 7
Channel 1
Alarm 1 set code
(Undefined) Alarm 2 set code
(Undefined) Alarm 1 set code
(Undefined) Alarm 2 set code
(Undefined)
(Undefined) alarm 2 set code
